Quest Courier Rocksim Design File

• Manufacturer: Quest
• Motor Size: 18 mm
• Power: Low-Power
• Recovery: Parachute
• Skill Level: 2
• Style: Egg Lofter
• Style: Payload

Comments: You can buy this kit from: www.ApogeeRockets.com. Note that the nose cone is made from a front portion, and a rear transition. This is how you can make any size nose cone you need for your own designs.

Designer: Dimension input by Tim Van Milligan

Download quest_courier.rkt

To use the design file above, you need a copy of Rocksim, a rocket design and simulation program.

Kit Name: Quest - Courier {Kit} (2011)
Diameter: 1.3100 inches
Length: 20.2500 inches
Style: Payload

CG: 9.4572 inches from front
CP: 15.7050 inches from front
Margin: 3.24 Overstable

Parts Breakdown

• Quest Courier Haack Nose Cone
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 0.50 in]
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 0.20 in]
• Custom Conical Transition
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 15.00 in]
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 2.63 in]
• Custom Ring
• Custom Ring
• Estes Engine hook Standard size Mass Object
• Quest Courier Trapezoid Fin Set Trapezoid Fin Set
• Estes Polyethylene LDPE Parachute (18.00 in)
• Estes Polyethylene LDPE Parachute (18.00 in)
