Rocketarium - Alamo Air-to-Air Missile Rocksim Design File

• Manufacturer: Rocketarium
• Recovery: Parachute
• Style: Scale

Comments: This simulation is based upon an actual kit build in summer 2021. Small, balsa detail parts are not included in the simulation.

Designer: Rocketarium; Rocksim file by David J. Thomas.

Download Rocketarium Alamo AA-10 (R27).rkt

To use the design file above, you need a copy of Rocksim, a rocket design and simulation program.

Kit Name: Rocketarium - Alamo Air-to-Air Missile {Kit} (RK-ALAMO)
Diameter: 1.6370 inches
Length: 30.1300 inches
Style: Scale

Parts Breakdown

• Apo11o Ogive Nose Cone
• Estes Mass Object
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 7.09 in]
• LOC Precision SC-250 1/4 In Elastic shock cord Mass Object
• Semroc G10 (PML 0.062") Parachute (17.76 in)
• Custom 1/8 Aircraft Plywood Ring (0.2500 - 1.5902 in)
• Estes Mass Object
• Custom Balsa Trapezoid Fin Set
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 16.14 in]
• Estes Paper Ring (1.5500 - 1.5902 in)
• Custom 1/8 Aircraft Plywood Ring (0.2500 - 1.5902 in)
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 4.25 in]
• Apo11o Paper Ring (0.7382 - 0.9551 in)
• Estes Engine hook Standard size Mass Object
• Apo11o Basswood Ring (0.9799 - 1.5902 in)
• Apo11o Basswood Ring (0.9799 - 1.5902 in)
• Apogee 13056 Launch Lug
• Apogee 13056 Launch Lug
• Custom Basswood Trapezoid Fin Set
• Custom Balsa Freeform Fin Set
• Custom Conical Transition
