Astron Beta K-45 Rocksim Design File

Contributed by Robert Ziegler

Designer: Estes Industries, 1970 Rocsim design by Mark Kulka, 11/2007

Download oop_estes_beta.rkt

To use the design file above, you need Rocksim which is available from Apogee's website.

CG: 7.3567 inches from front
CP: 11.5750 inches from front
Margin: 7.75 Overstable

Parts Breakdown

• Estes Ogive Nose Cone
• Semroc SE-2 Screw eye 3/4" Mass Object
• Estes Paper Body Tube (0.5440 in)
• Semroc Paper Ring (0.4130 - 0.5180 in)
• Estes Balsa Freeform Fin Set
• FlisKits SC-1-18 Shock Cord 18in Mass Object
• Apogee Components Polyethylene LDPE Parachute (12.00 in)
• Semroc Paper Launch Lug (0.1250 in)
• Semroc Paper Launch Lug (0.1250 in)
• Estes Paper Body Tube (0.5440 in)
• Estes Balsa Freeform Fin Set
