Binder Sentinel Rocksim Design File

• Family: Binder Design : Sentinel
• Manufacturer: Binder Design
• Motor Size: 54 mm
• Power: High-Power
• Recovery: Parachute
• Style: Sport

Comments: Level 2 (Second Attempt)

Designer: Binder

Download binder_design_sentinel54_6lb_empty.rkt

To use the design file above, you need a copy of Rocksim, a rocket design and simulation program.

Kit Name: Binder Design - Sentinel 54mm {Kit}

CG: 53.5026 inches from front
CP: 65.8314 inches from front
Margin: 3.08 Overstable

Parts Breakdown

• Binder Sentinel Ogive Nose Cone
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 36.00 in]
• Binder Design CP-3.90 Ring
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 34.00 in]
• Binder Design BH-3.9 Ring
• Binder Sentinel Freeform Fin Set Freeform Fin Set
• Binder Design CR-3.9-54mm Ring
• Binder Design CR-3.9-54mm Ring
• Binder Design Rip stop nylon Parachute (45.00 in)
• Binder Design LL-50 Launch Lug
• Binder Design LL-50 Launch Lug
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 17.00 in]
• Custom Ring
• Custom Ring
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 11.00 in]
