MK109 Stingray Rocksim Design File

Contributed by Bruce Levison

Comments: Flies unstable on C motors, Stable with B motor in low wind

Designer: Drawn by Bruce S. Levison

Download oop_estes_mk109.rkt

To use the design file above, you need Rocksim which is available from Apogee's website.

CG: 10.2362 inches from front
CP: 12.2316 inches from front
Margin: 1.81

Parts Breakdown

• Custom Ogive Nose Cone
• Custom Cardboard Body Tube (1.1024 in)
• Custom Polystyrene PS Freeform Fin Set
• Custom Cardboard Body Tube (0.7362 in)
• Custom Polyethylene LDPE Parachute (12.00 in)
• Custom Polystyrene PS Launch Lug (0.2677 in)
• Custom Polystyrene PS Launch Lug (0.2677 in)
• Custom Polystyrene PS Launch Lug (0.2362 in)
• Custom Polystyrene PS Ring (0.7362 - 1.0433 in)
• Custom Polystyrene PS Ring (0.7362 - 1.0433 in)
