oop_estes_pathfinder.rkt Rocksim Design File

Contributed by Darrell Smith

Download oop_estes_pathfinder.rkt

To use the design file above, you need Rocksim which is available from Apogee's website.

CG: 0.0000 inches from front
CP: 36.8693 inches from front
Margin: 27.83 Overstable

Parts Breakdown

• Estes Parabolic Nose Cone
• Estes Paper Body Tube (1.3250 in)
• Estes Conical Transition
• Estes Paper Body Tube (1.6370 in)
• Custom Cardboard Ring (0.9760 - 1.5950 in)
• Custom Cardboard Ring (0.9760 - 1.5950 in)
• Estes Engine hook Mini size Mass Object
• Estes Paper Launch Lug (0.1880 in)
• Estes Paper Launch Lug (0.1880 in)
• Custom Balsa Freeform Fin Set
• Custom Mass Object
• Estes Polyethylene LDPE Parachute (18.00 in)
• Estes Paper Body Tube (0.9760 in)
• Custom Cardboard Ring (0.0000 - 0.9500 in)
