Raven Rocksim Design File

• Manufacturer: Custom Rockets
• Recovery: Parachute
• Skill Level: 1
• Style: Sport

Comments: Custom Kit #10040

Designer: Custom

Download custom_raven.rkt

To use the design file above, you need a copy of Rocksim, a rocket design and simulation program.

Kit Name: Custom Rockets - Raven {Kit} (10040)
Diameter: 0.9760 inches
Length: 14.5000 inches
Style: Sport

CG: 7.3361 inches from front
CP: 13.0472 inches from front
Margin: 5.85 Overstable

Parts Breakdown

• Raven Parabolic Nose Cone
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 2.76 in]
• Custom Ring
• Custom Polyethylene LDPE Parachute (12.00 in)
• Custom Mass Object
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 9.02 in]
• Custom BT 50 to BT 20 Ring
• Custom BT 50 to BT 20 Ring
• Estes ESTES 2321 Launch Lug
• Raven Freeform Fin Set Freeform Fin Set
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 2.76 in]
• Custom Mass Object
• Custom Ring
