SDI Satellite (Sim Rev 2) Rocksim Design File

Contributed by Dick Stafford

Designer: Estes

Download oop_estes_sdi_satellite_rsim7.rkt

To use the design file above, you need Rocksim which is available from Apogee's website.

CG: 6.3750 inches from front
CP: 9.7104 inches from front
Margin: 9.81 Overstable

Parts Breakdown

• Custom PowerSeries Nose Cone
• Custom Conical Transition
• Custom Conical Transition
• Estes Polystyrene PS Body Tube (1.4000 in)
• Custom Polystyrene PS Body Tube (1.1250 in)
• Custom Conical Transition
• Custom Conical Transition
• Custom Conical Transition
• Custom Conical Transition
• Custom Polystyrene PS Body Tube (1.6250 in)
• Custom Conical Transition
• Estes Paper Body Tube (1.3250 in)
• Estes Polyethylene LDPE Parachute (12.00 in)
• Custom Paper Trapezoid Fin Set
• Custom Paper Trapezoid Fin Set
• Custom Balsa Trapezoid Fin Set
• Custom Balsa Trapezoid Fin Set
• Estes Paper Body Tube (0.7360 in)
• Estes Paper Ring (0.0000 - 0.7100 in)
• Estes Paper Ring (0.7360 - 1.2630 in)
