Airborne Surveillance Missile Rocksim Design File

• Family: Estes : Airborne Surveillance Missile
• Manufacturer: Estes
• Power: Low-Power
• Recovery: Parachute
• Style: Military

Comments: My first (re)design with Rocksim

Designer: Estes Industries (redesign by Jeff Kodysz)

Download oop_estes_asm.rkt

To use the design file above, you need a copy of Rocksim, a rocket design and simulation program.

Kit Name: Estes - Airborne Surveillance Missile {Kit} (867) [1983-1985]
Style: Military

Parts Breakdown

• Estes Airborne Surveillance Miss Nose Cone
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 6.50 in]
• SubAssembly
• Custom ASMR1 Ring
• Custom ASMR1 Ring
• Custom Ring
• Estes Airborne Surveillance Miss Freeform Fin Set
• Estes Airborne Surveillance Miss Freeform Fin Set
• Estes ESTES 2321 Launch Lug
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 2.50 in]
• Custom Mylar Streamer (0.0020 in)
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 3.50 in]
• Estes Airborne Surveillance Miss Freeform Fin Set
• Estes 30162-2 Ring
