GBU-24 Paveway III Rocksim Design File

• Manufacturer: Estes

Comments: Fin reinforcements modified to allow for correct placement in design

Designer: Jared Elliott

Download oop_estes_paveway_iii.rkt

To use the design file above, you need a copy of Rocksim, a rocket design and simulation program.

Kit Name: Estes - GBU-24 Paveway III {Kit} (2053) [2003-2005]

CG: 12.1463 inches from front
CP: 16.3283 inches from front
Margin: 5.68 Overstable

Parts Breakdown

• Estes GBU-24 Paveway III Ellipti Nose Cone
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 5.00 in]
• Estes GBU-24 Paveway III Trapezo Trapezoid Fin Set
• Estes Conical Transition
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 10.75 in]
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 5.00 in]
• Estes Eng. Hook Sleeve Ring
• Estes Engine hook Standard size Mass Object
• Estes 30162-2 Ring
• Estes GBU-24 Paveway III Freefor Freeform Fin Set
• Estes 30125 Ring
• Estes 30125 Ring
• Estes Polyethylene LDPE Parachute (12.00 in)
• Custom Mass Object
• Estes GBU-24 Paveway III Freefor Freeform Fin Set
• Estes Conical Transition
