The Launch Pad Hellfire AGM-114A Rocksim Design File

• Manufacturer: The Launch Pad
• Motor Size: 24 mm
• Power: Low-Power
• Power: Mid-Power
• Recovery: Parachute
• Scale: AGM-114 Hellfire
• Skill Level: 3
• Style: Scale

Download Hellfire.rkt

To use the design file above, you need a copy of Rocksim, a rocket design and simulation program.

Kit Name: The Launch Pad - Hellfire AGM-114A {Kit} (K054)
Diameter: 2.6000 inches
Style: Scale

CG: 7.4507 inches from front
CP: 12.5941 inches from front
Margin: 1.98

•

Parts Breakdown

• The Launch Pad Hellfire AGM-114A Nose Cone
• Semroc Mass Object
• Semroc SE-10 Screw Eye Mass Object
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 10.00 in]
• BalsaMachining.com C80-4 Ring
• The Launch Pad Hellfire AGM-114A Trapezoid Fin Set
• Apogee Components Polyethylene LDPE Parachute (17.99 in)
• Custom Ring
• Semroc Mass Object
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 10.25 in]
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 4.00 in]
• Apogee EB-50 Ring
• Semroc EH-38 Engine Hook E Mass Object
• BalsaMachining.com CR5080-F Ring
• BalsaMachining.com CR5080-F Ring
• The Launch Pad Hellfire AGM-114A Trapezoid Fin Set
• Estes ESTES 2328 Launch Lug
