Custom Elite #10025 Rocksim Design File

Contributed by Bruce Levison

• Manufacturer: Custom Rockets
• Motor Size: 18 mm
• Power: Low-Power
• Recovery: Parachute
• Skill Level: 2
• Style: Contest
• Style: Payload

Comments: Another Simulation By Bruce S. Levison

Designer: Custom Riockets Egg lofter kit #10025

Download custom_elite.rkt

To use the design file above, you need a copy of Rocksim, a rocket design and simulation program.

Kit Name: Custom Rockets - Elite {Kit} (10025) [1999-]
Diameter: 0.7360 inches
Length: 15.3700 inches
Style: Contest

CG: 5.8723 inches from front
CP: 12.0329 inches from front
Margin: 3.29 Overstable

Parts Breakdown

• Custom Elite #10025 Parabolic Nose Cone
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 0.62 in]
• LOC Precision Mass Object
• Balsa Machining Service Conical Transition
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 9.00 in]
• Custom Elite #10025 Freeform Fin Freeform Fin Set
• Custom Elite #10025 Trapezoid Fi Trapezoid Fin Set
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 0.50 in]
• Estes ESTES 2321 Launch Lug
• Estes 30162-2 Ring
• LOC Precision Mass Object
• Estes Mylar Parachute (20.00 in)
• Custom Elite #10025 Trapezoid Fi Trapezoid Fin Set
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 0.50 in]
• Estes ESTES 2321 Launch Lug
