oop_estes_space_shuttle.rkt Rocksim Design File

Contributed by Jeff Caldwell

Download oop_estes_space_shuttle.rkt

To use the design file above, you need Rocksim which is available from Apogee's website.

CG: 7.7919 inches from front
CP: 10.6177 inches from front
Margin: 1.39

Parts Breakdown

• Estes Ogive Nose Cone
• Semroc Spiral/Glassine Body Tube (2.0400 in)
• External Pod
• Custom Conical Transition
• Rogue Aerospace Paper Body Tube (0.8750 in)
• Estes Paper Body Tube (0.7500 in)
• Custom Cardboard Ring (0.0000 - 0.6875 in)
• Apogee Components Paper Ring (0.8125 - 0.8750 in)
• Apogee Components Paper Ring (0.8125 - 0.8750 in)
• Custom Balsa Trapezoid Fin Set
• Custom Balsa Trapezoid Fin Set
• Custom Birch Freeform Fin Set
• Custom Cardboard Ring (0.8750 - 0.9063 in)
• Custom Conical Transition
• External Pod
• Custom Conical Transition
• Rogue Aerospace Paper Body Tube (0.8750 in)
• Estes Paper Body Tube (0.7500 in)
• Custom Cardboard Ring (0.0000 - 0.6875 in)
• Apogee Components Paper Ring (0.8125 - 0.8750 in)
• Apogee Components Paper Ring (0.8125 - 0.8750 in)
• Custom Balsa Trapezoid Fin Set
• Custom Balsa Trapezoid Fin Set
• Custom Birch Freeform Fin Set
• Custom Cardboard Ring (0.8750 - 0.9063 in)
• Custom Conical Transition
• Estes Paper Body Tube (0.7360 in)
• Estes Paper Ring (0.7360 - 0.7441 in)
• Estes Engine hook Standard size Mass Object
• Estes Polyethylene LDPE Parachute (18.00 in)
• Custom Polycarbonate Freeform Fin Set
• Custom Polycarbonate Freeform Fin Set
• Custom Birch Freeform Fin Set
• Estes Paper Launch Lug (0.1250 in)
• Estes Paper Launch Lug (0.1250 in)
• Custom Polycarbonate Freeform Fin Set
• Apogee Components Paper Ring (0.7360 - 2.0000 in)
• Apogee Components Paper Ring (0.7360 - 2.0000 in)
• External Pod
• Apogee Components Paper Body Tube (0.0002 in)
• Custom Polystyrene PS Freeform Fin Set
• Custom Cardboard Freeform Fin Set
• External Pod
• Custom Haack Nose Cone
• Custom Mass Object
• Custom Rockets Polystyrene PS Body Tube (1.2500 in)
• Custom Polystyrene PS Freeform Fin Set
• Custom Ogive Transition
• Custom Elliptical Transition
