Seieron 3 Rocksim Design File

• Manufacturer: Starlight Rockets

Comments: 3 cluster 18mm One BT-20 tube will make all three motor mount tubes. Fins are mounted between motor tubes. Nosecone,top tube, and top of transition are all one piece. Rocket separates at rear of transition.

Designer: Starlight Rocketry Rocksim by Marlin Meyer February, 2010 All part numbers are Semroc

Download starlight_seieron3.rkt

To use the design file above, you need a copy of Rocksim, a rocket design and simulation program.

Kit Name: Starlight Rockets - Seieron 3 {Kit}

CG: 20.5818 inches from front
CP: 24.6493 inches from front
Margin: 5.53 Overstable

Parts Breakdown

• Double Barrel Elliptical Nose Cone
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 8.00 in]
• Apogee Components Conical Transition
• Semroc SE-10 Screw Eye Mass Object
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 12.00 in]
• Semroc Mass Object
• Semroc Polyethylene LDPE Parachute (16.00 in)
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 6.00 in]
• SEMROC Astronautics EB-20A Ring
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 6.00 in]
• SEMROC Astronautics EB-20A Ring
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 6.00 in]
• SEMROC Astronautics EB-20A Ring
• Seieron 3 Freeform Fin Set Freeform Fin Set
• SEMROC Astronautics LL-2A Launch Lug
• SEMROC Astronautics LL-2A Launch Lug
