U.S. Rockets Warp 1-5 Rocksim Design File

• Manufacturer: U.S. Rockets

Designer: US Rockets

Download usr_warp_1_5.rkt

To use the design file above, you need a copy of Rocksim, a rocket design and simulation program.

Kit Name: U.S. Rockets - Warp 1-5 {Kit}

CG: 24.3630 inches from front
CP: 36.2005 inches from front
Margin: 4.55 Overstable

Parts Breakdown

• U.S. Rockets Warp 1 Ogive Nose Cone
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 18.00 in]
• Custom Ring
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 18.00 in]
• U.S. Rockets Sonic 2700 Trapezoi Trapezoid Fin Set
• Public Missiles HDWE-EYE-1/8 1/8x24 Mass Object
• LOC Precision SC-250 1/4 In Elastic shock cord Mass Object
• Estes Rip stop nylon Parachute (24.00 in)
• LOC LOC LL25 Launch Lug
• LOC LOC LL25 Launch Lug
• Custom Ring
• Custom Ring
• Custom Ring
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 6.00 in]
