Flight Log - 2015-08-30 - Rick Barnes's Advanced Target Drone 2.25X
I built this upscale of an Estes Advanced Target Drone after building a clone of the original and finding that Excelsior made upscale decals in this size. It was a little more challenging than other upscales that Ive done, insomuch as I made the body shrouds out of 1/16th ply, and designed to build it as a 3x24mm cluster while I was at it. The added motor mounts are parallel the to the main mount in the shrouds. It came out a little heavier than I'd hoped, at 13.5 oz, but it should fly fine on 3 D12's or a single E30 composite.
| Flight Date: | 2015-08-30 |
| Rocket Name: | Advanced Target Drone 2.25X |
| Flyer's Name: | Rick Barnes |
| Motors: | 2xD11-p+D12-7 |
| Launch Site: | Torrey Farm, Potter, NY |
| Actual Altitude: | 900.00 Feet |
Good flight. All three motors lit, and the rocket landed close by in the carrots. The recently lengthened shock cord seems to have help prevent additional wing-whacks.
| Stage | Motor(s) |
|---|---|
| 1 | 2 x Estes D11-p |
| Estes D12-7 |
