Aerotech G40W - Time-Thrust Curve and Data

The G40W (G40) is a 24% G single-use motor from Aerotech.

Aerotech's White Lightning propellant produces a brilliant white flame and white smoke.

Average Thrust: 43.0520 N
CSFM Classification: Model Rocket Motor
Class: 24% G
Delays: 4,7,10 s seconds
Designation: G40W
Diameter: 29.0000 mm
Formula: White Lightning
Length: 124.0000 mm
Letter: G
Manufacturer: Aerotech
Name: G40
Peak Thrust: 74.3250 N
Thrust Duration: 2.3000 s
Total Impulse: 99.0200 Ns
Total Weight: 123.0000 g
Type: Single-Use
