Vanguard TV-4.rkt Trapezoid Fin Set Trapezoid Fin Set| Manufacturer: | Custom | | Part Number: | | | Style: | Trapezoid Fin Set | | Material: | Balsa |
Download as PDF | Root Chord: | 13.0000 inches (330.2000 mm) | | Tip Chord: | 12.8000 inches (325.1200 mm) | | Sweep Distance: | 0.0063 inches (0.1600 mm) | | SemiSpan: | 0.1250 inches (3.1750 mm) | | Point 1: | (0.0000 mm, 0.0000 mm) | | Point 2: | (3.1750 mm, 0.1600 mm) | | Point 3: | (3.1750 mm, 325.2800 mm) | | Point 4: | (0.0000 mm, 330.2000 mm) | | Width: | 0.1250 inches (3.1750 mm) | | Height: | 13.0000 inches (330.2000 mm) |
