Estes AMRAAM AIM-120 Freeform Fi Freeform Fin Set

Manufacturer:Custom
Part Number:
Style:Freeform Fin Set
Material:Balsa

Download as PDF

Point 1:(0.0000 mm, 76.2000 mm)
Point 2:(57.1500 mm, 76.2000 mm)
Point 3:(57.1500 mm, 63.5000 mm)
Point 4:(13.1344 mm, -0.1251 mm)
Point 5:(0.0000 mm, 0.0000 mm)
Width:3.0000 inches (76.2000 mm)
Height:3.0049 inches (76.3251 mm)
