AIM-54 Phoenix Trapezoid Fin Set Trapezoid Fin Set

Manufacturer:Custom
Part Number:
Style:Trapezoid Fin Set
Material:Balsa

Download as PDF

Root Chord:2.6250 inches (66.6750 mm)
Tip Chord:2.6250 inches (66.6750 mm)
Sweep Distance:0.0000 inches (0.0000 mm)
SemiSpan:2.6250 inches (66.6750 mm)
Point 1:(0.0000 mm, 0.0000 mm)
Point 2:(66.6750 mm, 0.0000 mm)
Point 3:(66.6750 mm, 66.6750 mm)
Point 4:(0.0000 mm, 66.6750 mm)
Width:2.6250 inches (66.6750 mm)
Height:2.6250 inches (66.6750 mm)
