Pershing Missile Trapezoid Fin S Trapezoid Fin Set| Manufacturer: | Custom | | Part Number: | | | Style: | Trapezoid Fin Set | | Material: | Birch |
Download as PDF | Root Chord: | 4.0000 inches (101.6000 mm) | | Tip Chord: | 4.0000 inches (101.6000 mm) | | Sweep Distance: | 0.0000 inches (0.0000 mm) | | SemiSpan: | 4.1250 inches (104.7750 mm) | | Point 1: | (0.0000 mm, 0.0000 mm) | | Point 2: | (104.7750 mm, 0.0000 mm) | | Point 3: | (104.7750 mm, 101.6000 mm) | | Point 4: | (0.0000 mm, 101.6000 mm) | | Width: | 4.1250 inches (104.7750 mm) | | Height: | 4.0000 inches (101.6000 mm) |
