LOC/Precision V2 (7.5") Freeform Freeform Fin Set| Manufacturer: | LOC/Precision | | Part Number: | | | Style: | Freeform Fin Set | | Material: | Aircraft plywood (LOC) |
Download as PDF | Point 1: | (0.0000 mm, 445.1000 mm) | | Point 2: | (45.0000 mm, 470.0000 mm) | | Point 3: | (120.0000 mm, 470.0000 mm) | | Point 4: | (100.0000 mm, 170.0000 mm) | | Point 5: | (0.0000 mm, 0.0000 mm) | | Width: | 17.5236 inches (445.1000 mm) | | Height: | 18.5039 inches (470.0000 mm) |
