Rocketry Parts Database >> Fins >>

Performance Rocketry Mad Maxx Tr Trapezoid Fin Set

Manufacturer:LOC/Precision
Part Number:
Style:Trapezoid Fin Set
Material:G10 fiberglass

Download as PDF

Root Chord:17.0000 inches (431.8000 mm)
Tip Chord:4.0000 inches (101.6000 mm)
Sweep Distance:11.6569 inches (296.0853 mm)
SemiSpan:6.8750 inches (174.6250 mm)
Point 1:(0.0000 mm, 0.0000 mm)
Point 2:(174.6250 mm, 296.0853 mm)
Point 3:(174.6250 mm, 397.6853 mm)
Point 4:(0.0000 mm, 431.8000 mm)
Width:6.8750 inches (174.6250 mm)
Height:17.0000 inches (431.8000 mm)
