Rocketry Parts Database >> Fins >>

Space Ark Jr. Trapezoid Fin Set Trapezoid Fin Set

Manufacturer:Pem Tech
Part Number:
Style:Trapezoid Fin Set
Material:Balsa

Download as PDF

Root Chord:0.5600 inches (14.2240 mm)
Tip Chord:0.5600 inches (14.2240 mm)
Sweep Distance:0.0000 inches (0.0000 mm)
SemiSpan:1.3000 inches (33.0200 mm)
Point 1:(0.0000 mm, 0.0000 mm)
Point 2:(33.0200 mm, 0.0000 mm)
Point 3:(33.0200 mm, 14.2240 mm)
Point 4:(0.0000 mm, 14.2240 mm)
Width:1.3000 inches (33.0200 mm)
Height:0.5600 inches (14.2240 mm)
