X-Ray Rocksim Design File

• Manufacturer: Estes

Comments: The launch lug needs a 1/8" x 1/8" x 2" balsa standoff.

Designer: Estes Industries, Inc., (data entered by Charles Keller based on Kit #18 instructions)

Download oop_estes_x_ray.rkt

To use the design file above, you need a copy of Rocksim, a rocket design and simulation program.

Kit Name: Estes - X-Ray {Kit} (18) [1965-1985]

CG: 8.2421 inches from front
CP: 14.6034 inches from front
Margin: 6.52 Overstable

Parts Breakdown

• Denton - Estes Payloader II.rkt Nose Cone
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 4.00 in]
• Custom Conical Transition
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 8.65 in]
• Estes X-Ray Trapezoid Fin Set Trapezoid Fin Set
• Estes ESTES 2321 Launch Lug
• DIY Eye Hook #4 Mass Object
• Custom Mass Object
• Estes Polyethylene LDPE Parachute (12.00 in)
• Estes 30162-2 Ring
