WAC Corporal Rocksim Design File

Contributed by Kurt Savegnago

• Designer: Andy Jackson
• Manufacturer: Aerospace Specialty Products
• Motor Size: 38 mm
• Power: Mid-Power
• Recovery: Parachute
• Scale: WAC Coporal
• Scale: WAC Corporal
• Skill Level: 2
• Style: Scale

Designer: ASP

Download asp_wac_corporal_38mm.rkt

To use the design file above, you need a copy of Rocksim, a rocket design and simulation program.

Kit Name: Aerospace Specialty Products - WAC Corporal (38mm) {Kit} (KWAC-38)
Diameter: 2.6500 inches
Length: 43.0000 inches
Style: Scale

CG: 29.0000 inches from front
CP: 38.4934 inches from front
Margin: 3.46 Overstable

Parts Breakdown

• WAC Corporal Power Series Nose Cone
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 30.50 in]
• BalsaMachining.com C80-6 Ring
• BalsaMachining.com BHC80-W Ring
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 15.00 in]
• Public Missiles LL-0.25 Launch Lug
• WAC Corporal Freeform Fin Set Freeform Fin Set
• WAC Corporal Freeform Fin Set Freeform Fin Set
• WAC Corporal Freeform Fin Set Freeform Fin Set
• WAC Corporal Freeform Fin Set Freeform Fin Set
• Custom Ring
• BalsaMachining.com LOC CR-3.00-1 Ring
• Custom 1.3 oz. Ripstop Nylon (SkyAngle) Parachute (48.75 in)
• Custom Conical Transition
