Skyraider Rocksim Design File

Contributed by Darrell Smith

• Manufacturer: Estes

Designer: Darrell Smith

Download oop_estes_sky_raider.rkt

To use the design file above, you need a copy of Rocksim, a rocket design and simulation program.

Kit Name: Estes - Sky Raider {Kit} (1290) [1977-1983]

CG: 19.2320 inches from front
CP: 27.2009 inches from front
Margin: 6.04 Overstable

Parts Breakdown

• Baby_Cherokee.rkt Ogive Nose Cone
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 9.00 in]
• Aerospace Speciality Products BH Ring
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 18.00 in]
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 2.75 in]
• BalsaMachining.com EB24-P Ring
• Estes Engine hook Standard size Mass Object
• FlisKits CRF-50-55 Ring
• FlisKits CRF-50-55 Ring
• Estes Polyethylene LDPE Parachute (18.00 in)
• Public Missiles Mass Object
• Semroc SE-12 Screw Eye-Large Mass Object
• Estes Skyraider Freeform Fin Set Freeform Fin Set
