Estes - Mini Honest John Rocksim Design File

Comments: - Overall Mass Override selected for acutal weight and CG NOTE: the stability is MARGINAL once an engine is loaded. This Rocksim file is the stock kit constructed as per instructions. There is a previous version of this model identical in size and dimension - except it was released with an 18mm motor mount - that model shows clay in the nose cone, which will move the CG forward, which is what I will recommend adding.

Designer: Estes Mini Honest John (13mm motor mount) #2446 Rocksim v8 By Doug Szczepanski Sr.

Download Mini Honest John - est2446.rkt

To use the design file above, you need a copy of Rocksim, a rocket design and simulation program.

Kit Name: Estes - Mini Honest John {Kit} (2446)
Diameter: 0.9800 inches
Length: 11.7500 inches
Style: Scale

CG: 7.2500 inches from front
CP: 8.9510 inches from front
Margin: 1.35
