Estes - Alpha - Rocksim Design File

Estes - Alpha Rocksim Design File

Comments: The dimensions for this rocket were found in the booklet: TR-11. The purpose was to find the Drag Coefficient of a basic and popular model.

Download estes_alpha - Anderson update parachute 10-31-17.rkt

To use the design file above, you need a copy of Rocksim, a rocket design and simulation program.

Kit Name: Estes - Alpha {Kit} (25) [1966-]
Diameter: 0.9800 inches
Length: 12.3000 inches
Style: Sport

Parts Breakdown

Estes - Alpha Ogive Nose Cone

Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 8.00 in]

Estes 1/8" rubber band Mass Object

Alpha D Trapezoid Fin Set Trapezoid Fin Set

Estes "1/8""" Launch Lug

Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 2.75 in]

Estes Engine hook Standard size Mass Object

Apogee #13031 CR 18-24 Ring

Estes Polyethylene LDPE Parachute (12.00 in)
