Estes ESAM-58 Rocksim Design File

Comments: Another simulation by Bruce S. Levison. Drawn from Kit dated 06/01/19

Designer: Estes ESAM-58 EST0661 Hobby Lobby Exclusive

Download Estes ESAM-58 EST0661.rkt

To use the design file above, you need a copy of Rocksim, a rocket design and simulation program.

Parts Breakdown

• Estes Elliptical Nose Cone
• Estes Ogive Transition
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 18.00 in]
• Estes Polyethylene LDPE Parachute (18.00 in)
• Estes 038363 1/4" Flat Rubber Shock Cord Mass Object
• Estes Balsa Freeform Fin Set
• Estes Paper Launch Lug (0.1700 in)
• Estes Paper Ring (0.7400 - 1.5900 in)
• Estes Balsa Freeform Fin Set
• Estes Paper Launch Lug (0.1700 in)
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 3.50 in]
• Estes 30162-2 Ring
• Estes Paper Ring (0.7400 - 1.5900 in)
• Estes Conical Transition
• Estes Conical Transition
• Estes Conical Transition
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 0.40 in]
• Custom Polystyrene PS Ring (0.8700 - 1.0000 in)
