Astrocam Rocksim Design File

Contributed by Andy Hobbs

• Designer: Mike Dorffler
• Manufacturer: Estes
• Motor Size: 18 mm
• Power: Low-Power
• Recovery: Parachute
• Skill Level: 1
• Style: Payload

Comments: drawn bt A.hobbs

Designer: Estes

Download estes_rtf_astrocam.rkt

To use the design file above, you need a copy of Rocksim, a rocket design and simulation program.

Kit Name: Estes - Astrocam {Kit} (1813)
Diameter: 1.3400 inches
Length: 18.0000 inches
Style: Payload

CG: 9.5491 inches from front
CP: 16.6320 inches from front
Margin: 5.26 Overstable

Parts Breakdown

• Astrocam Elliptical Nose Cone
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 13.00 in]
• Custom Ring
• Custom Ring
• Custom Launch Lug
• Custom Mylar Parachute (12.25 in)
• Astrocam Freeform Fin Set Freeform Fin Set
• Custom Launch Lug
• Custom Launch Lug
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 3.37 in]
