3FNC 3" Rocksim Design File

• Manufacturer: Pemberton Technologies

Comments: 01/21/05 Approved for flight.

Designer: Layne Pemberton - Pemberton Technologies

pem_tech@yahoo.com

http://laynepemberton.com/pembertontechnologies/

Download pemberton_3fnc_3inch.rkt

To use the design file above, you need a copy of Rocksim, a rocket design and simulation program.

Kit Name: Pemberton Technologies - 3FNC {Kit}

CG: 10.5209 inches from front
CP: 16.1855 inches from front
Margin: 1.83

Parts Breakdown

• 3FNC 3" Ogive Nose Cone
• Custom Mass Object
• Custom Mass Object
• PemTech WL-8 .0625 wire lead-eight inch Mass Object
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 4.00 in]
• Pemberton Technologies 2.62 Ring
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 11.00 in]
• 3FNC 3" Trapezoid Fin Set Trapezoid Fin Set
• Top FLight Rip stop nylon Parachute (17.99 in)
• Custom Mass Object
• Pemberton Technologies LL-375 Launch Lug
• Pemberton Technologies LL-038 Launch Lug
• Custom Ring
• Public Missiles CR-3.0-1.1 Ring
• Pemberton Technologies Conical Transition
• Pemberton Technologies MR-29 Motor retainer for 29mm Motor mount Mass Object
