Wildman Rocketry Wildman Junior Rocksim Design File

• Manufacturer: Wildman Rocketry

Comments: Rocksim file by Mark Koelsch

Designer: Tim Lehr

Download wildman_wildman_junior.rkt

To use the design file above, you need a copy of Rocksim, a rocket design and simulation program.

Kit Name: Wildman Rocketry - Wildman Junior {Kit}

CG: 32.1308 inches from front
CP: 46.7395 inches from front
Margin: 6.41 Overstable

Parts Breakdown

• Wildman Rocketry Darkstar Ogive Nose Cone
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 16.00 in]
• Wildman 3/32"x2" G10 Nosecone Bu Ring
• Wildman 1/4"x20' Tubular Kevlar 1/4"x20' Tubular Kevlar Mass Object
• Wildman 1/8" Quicklink 1/8" Quicklink Mass Object
• Wildman 1/4" Welded Eyebolt 1/4" Welded Eyebolt Mass Object
• Wildman 3/32"x 54mm G10 Coupler Ring
• Wildman 54mm G10 Coupler Ring
• Wildman 3/32"x54mm G10 bulkhead Ring
• Wildman 1/8" Quicklink 1/8" Quicklink Mass Object
• Wildman 1/4" Welded Eyebolt 1/4" Welded Eyebolt Mass Object
• b2 Rocketry 1.3 oz. Ripstop Nylon (SkyAngle) Parachute (32.00 in)
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 1.00 in]
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 30.00 in]
• Wildman 3/32"x 54mm G10 Coupler Ring
• Railbuttons 1010 Nylon Rail Butt Launch Lug
• Railbuttons 1010 Nylon Rail Butt Launch Lug
• Wildman 1/4"x20' Tubular Kevlar 1/4"x20' Tubular Kevlar Mass Object
• Wildman 1/8" Quicklink 1/8" Quicklink Mass Object
• Wildman 54mmx38mm Plywood Center Ring
• Wildman 54mmx38mm Plywood Center Ring
• Wildman Rocketry Wildman Junior Trapezoid Fin Set
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 8.50 in]
• Wildman 1/4" Welded Eyebolt 1/4" Welded Eyebolt Mass Object
• Wildman 3/32"x54mm G10 bulkhead Ring
• Apogee Components Mylar Streamer (0.0001 in)
