ISQY Tomahawk Rocksim Design File

• Designer: Dan Meyer
• Designer: Marc McReynolds
• Manufacturer: Aerotech
• Power: Mid-Power
• Recovery: Parachute
• Scale: IQSY Tomahawk
• Style: Sport

Comments: RSim model by Brittain Fraley

Designer: Design from www.rocketreviews.com

Download aerotech_isqytomahawk.rkt

To use the design file above, you need a copy of Rocksim, a rocket design and simulation program.

Kit Name: Aerotech - ISQY Tomahawk {Kit} (89014) [1989-]
Style: Sport

CG: 27.5213 inches from front
CP: 35.9102 inches from front
Margin: 4.42 Overstable

Parts Breakdown

• Aerotech ISQY Tomahawk Ogive Nose Cone
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 9.00 in]
• Custom Ring
• Custom Ring
• Aerotech 19015 Screw Eye Mass Object
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 22.75 in]
• Aerotech 19035 Launch Lug
• Aerotech 19035 Launch Lug
• Aerotech 17388 Shock cord 8' Mass Object
• Aerotech 19015 Screw Eye Mass Object
• Custom Rip stop nylon Parachute (22.00 in)
• Aerotech ISQY Tomahawk Freeform Freeform Fin Set
• Aerotech 14829 Ring
• Aerotech 14829 Ring
• Aerotech 14829 Ring
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 12.00 in]
• Aerotech 14010 Ring
• Aerotech 19011 Cooling Mesh Mass Object
• Aerotech 19001 Motor Hook Mass Object
• Aerotech 19344 Ring
• Aerotech 19344 Ring
• Aerotech 19030 Ring
