Nova MRK-III Rocksim Design File

• Manufacturer: FSI
• Recovery: Parachute
• Style: Sport

Download oop_fsi_nova.rkt

To use the design file above, you need a copy of Rocksim, a rocket design and simulation program.

Kit Name: FSI - Nova (1003, MRK-3) [1967-1994]
Style: Sport

CG: 10.4912 inches from front
CP: 15.9252 inches from front
Margin: 5.90 Overstable

Parts Breakdown

• FSI Nova MRK-III Elliptical Nose Cone
• Semroc SE-10 Screw Eye Mass Object
• DIY 20mm steel fender washer Mass Object
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 8.00 in]
• Semroc Polyethylene LDPE Parachute (12.00 in)
• DIY Kevlar shock cord anchor Mass Object
• LOC Precision SC-250 1/4 In Elastic shock cord Mass Object
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 4.00 in]
• DIY Mass Object
• Semroc Conical Transition
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 6.00 in]
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 4.00 in]
• Semroc TR-9 Ring
• Semroc EH-38 Engine Hook E Mass Object
• FSI Nova MRK-III Trapezoid Fin S Trapezoid Fin Set
• Semroc LL-117 Launch Lug
