Saturn V 1/100 scale 30th Anniversary Rocksim Design File

Contributed by Don Edvalson

• Family: Estes : Saturn V
• Family: Estes : Saturn V (1/48)
• Manufacturer: Estes
• Motor Size: 24 mm
• Power: Low-Power
• Recovery: Parachute
• Scale: Saturn : Saturn V
• Skill Level: 4
• Skill Level: 5
• Style: Scale

Comments: Portions of the data are from a measured model, thus some numbers may be less than totally accurate

Designer: Unknown

Download oop_estes_saturn_v.rkt

To use the design file above, you need a copy of Rocksim, a rocket design and simulation program.

Kit Name: Estes - Saturn V {Kit} (2157) [1998-1998, 2010-2011, 2016]
Diameter: 3.9400 inches
Length: 43.2500 inches
Style: Scale

CG: 19.8846 inches from front
CP: 24.4415 inches from front
Margin: 3.04 Overstable

Parts Breakdown

• Estes Saturn V 1/100 scale 30th Nose Cone
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 1.87 in]
• Custom Conical Transition
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 4.12 in]
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 4.75 in]
• Estes Estes Ring
• Custom Ring
• Custom Ring
• Custom Ring
• Custom Ring
• Custom Conical Transition
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 3.75 in]
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 24.70 in]
• Estes Saturn V 1/100 scale 30th Trapezoid Fin Set
• Custom Launch Lug
• Custom Mass Object
• Custom Mass Object
• Estes Polyethylene LDPE Parachute (18.00 in)
• Custom Polyethylene LDPE Parachute (24.00 in)
• SubAssembly
• SubAssembly
• Estes Estes Ring
• Custom Ring
• Custom Ring
• SubAssembly
• Custom Ring
• Custom Ring
• Custom Ring
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 15.82 in]
• Custom Ring
• Custom Ring
• Custom Ring
• Custom Ring
• Custom Ring
• Custom Ring
• Custom Launch Lug
