Quest Tomahawk SLCM Rocksim Design File

• Manufacturer: Quest
• Recovery: Parachute
• Skill Level: 3
• Style: Scale

Comments: This is a kit you can buy from Apogee Components at: www.apogeerockets.com.

Designer: Bill Stine. RockSim data input by Tim Van Milligan.

Download quest_tomahawk.rkt

To use the design file above, you need a copy of Rocksim, a rocket design and simulation program.

Kit Name: Quest - Tomahawk {Kit} (3007) [1994-]
Diameter: 1.5760 inches
Length: 22.0000 inches
Style: Scale

CG: 8.5000 inches from front
CP: 13.0737 inches from front
Margin: 2.91 Overstable

Parts Breakdown

• Quest Tomahawk SLCM Elliptical Nose Cone
• Custom Mass Object
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 14.75 in]
• Custom Ring
• Custom Ring
• Custom Ring
• Quest Tomahawk SLCM Freeform Fin Freeform Fin Set
• Custom Polyethylene LDPE Parachute (14.00 in)
• Custom Mass Object
• Estes ESTES 2321 Launch Lug
• Custom Conical Transition
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 4.00 in]
• Quest Tomahawk SLCM Trapezoid Fi Trapezoid Fin Set
