Estes - Mini Fat Boy Rocksim Design File

Comments: By W. Darling

Designer: Estes #2442

Download Estes_Mini Fat Boy.rkt

To use the design file above, you need a copy of Rocksim, a rocket design and simulation program.

Kit Name: Estes - Mini Fat Boy {Kit} (002442) [2013-]
Diameter: 1.6400 inches
Length: 8.5000 inches
Style: Sport

Parts Breakdown

Estes - Mini Fat Boy Elliptical Nose Cone

Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 5.55 in]

Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 1.77 in]

Estes Engine hook Standard size Mass Object

Estes 30167 Ring

Estes 30222-4 Ring

Estes - Mini Fat Boy Trapezoid Fin Set Trapezoid Fin Set

Estes 038175 Launch Lug

Estes Paper Ring (0.5440 - 1.3900 in)

Estes Paper Ring (0.5440 - 1.3900 in)

Estes 038367 Shock Cord - 24" Mass Object

Estes Polyethylene LDPE Parachute (10.29 in)
