AGM-57X Heatseeker EST 2158 Rocksim Design File

Contributed by Bruce Levison

• Manufacturer: Estes
• Power: Low-Power
• Recovery: Parachute

Comments: Another Simulation by Bruce S. Levison, NAR #69055, Measured from Kit

Designer: Estes # 2158 Decal part #37501

Download estes_agm-57x_heatseeker.rkt

To use the design file above, you need a copy of Rocksim, a rocket design and simulation program.

Kit Name: Estes - AGM-57X Heatseeker {Kit} (002158) [1998-2004,2013-]
Diameter: 1.1000 inches
Length: 18.6000 inches

CG: 12.0181 inches from front
CP: 14.2492 inches from front
Margin: 2.04

Parts Breakdown

• Estes AGM-57X Heatseeker EST 215 Nose Cone
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 2.94 in]
• Custom Ring
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 11.06 in]
• Custom Launch Lug
• Custom Ring
• Custom Ring
• Custom Ring
• Estes AGM-57X Heatseeker EST 215 Freeform Fin Set
• Custom Launch Lug
• Custom Launch Lug
• Custom Mass Object
• Estes Polyethylene LDPE Parachute (12.00 in)
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 2.50 in]
• Custom Ring
• Estes Engine hook Standard size Mass Object
