Loc V2 Pre Production 29mm Rocksim Design File

• Family: LOC/Precision : V2
• Manufacturer: LOC/Precision
• Recovery: Parachute
• Scale: V-2
• Style: Scale

Comments: RockSim file by Mark Saunders, NAR # 78825 TRA # 09247

Designer: Barry Lynch

Download loc_v2_39in.rkt

To use the design file above, you need a copy of Rocksim, a rocket design and simulation program.

Kit Name: LOC/Precision - V2 (3.9") {Kit} (PK-57)
Diameter: 4.0000 inches
Length: 33.7500 inches
Style: Scale

CG: 16.2285 inches from front
CP: 24.4673 inches from front
Margin: 2.06

Parts Breakdown

• AGM-88 HARM Ogive Nose Cone
• Custom Mass Object
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 11.00 in]
• b2 Rocketry 1.3 oz. Ripstop Nylon (SkyAngle) Parachute (30.00 in)
• Giant Leap Shockloop-916-15 9-16in 15ft Nylon Loop Mass Object
• Public Missiles Ogive Transition
• Loc V2 Pre Production 29mm Freef Freeform Fin Set
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 12.00 in]
• Public Missiles CR-3.9-1.1 Ring
• Public Missiles CR-2.5-1.1 Ring
• Giant Leap Mass Object
