Orion Rocksim Design File

Contributed by Dynastar

• Designer: Douglas Shrock (Shrox)
• Manufacturer: DynaStar
• Motor Size: 24 mm
• Power: Low-Power
• Power: Mid-Power
• Recovery: Parachute
• Skill Level: 4
• Style: Military

Comments: Free Apogee Newsletter Plan

Designer: Shrox

Download dynastar_snarky.rkt

To use the design file above, you need a copy of Rocksim, a rocket design and simulation program.

Kit Name: DynaStar - Snarky {Kit} (05030)
Diameter: 2.2170 inches
Length: 28.5000 inches
Style: Military

CG: 16.5000 inches from front
CP: 21.8289 inches from front
Margin: 2.40

Parts Breakdown

• Orion Ogive Nose Cone
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 18.00 in]
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 4.00 in]
• Apogee 13031 Ring
• Orion Freeform Fin Set Freeform Fin Set
• Orion Trapezoid Fin Set Trapezoid Fin Set
• Orion Freeform Fin Set Freeform Fin Set
• Orion Freeform Fin Set Freeform Fin Set
• Apogee 13035 Ring
• Apogee 13035 Ring
• Apogee "1/8"" X 1" Launch Lug
• DynaStar Polyethylene LDPE Parachute (32.00 in)
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 17.50 in]
